DILLON DYNAMOMETERS DIGITAL AP ( 500lbf - 20.000lbf / 200kgf - 10.000kgf )
191
watching
17
sold in the last hour
Sale price
$5740.00 USD
SKU: DIL AP
Return Policy
Returns accepted if product not as described, buyer pays return shipping fee; or keep the product & agree refund with seller.
View details
Seller Guarantees:
On-time Delivery
25 days
Payment:
Buyer Protection
Full Refund if you don't receive your order.
Full or Partial Refund , if the item is not as described
Originally designed to measure the tension on telephone wires, the Dynamometer has proven to have limitless versatility as a tension and weight measuring instrument. It is used for such diverse jobs as suspended weighing; mounting cables for bridges; adjusting tension on guy wires; field testing chain, rope, wire—anything requiring precision force or tension measurement.
It has proven its value in such diverse jobs as mounting cables for bridges, adjusting tension on guy wires, field testing chain, rope, wire anything requiring precision force or tension measurement.
SPECIFICATIONS
Accuracy: + 0.5% of capacity
Temperature range: -50° to 140° F (-45° to 60° C)
Ultimate Safety Factor:
See table on cover for minimum USF
Construction:
Pressure bar -
Aircraft quality E4340 steel or 7075-T651 aluminum
Shackles -
A4140 forged steel (machined from E4340 steel)
Shackle pins -
Machined from E4340 steel
Case housing:
5” models are equipped with high strength composite plastic case.
10” models use cast aluminum enclosure.
Corrosion protection: Pressure bar protected with durable powder coat paint. Shackles and pins are electroless nickel plated. All integral machining and fasteners are produced from noncorrosive materials or have suitable plating.
Zero control: Zero up to 20% of capacity. Zeroed load must be considered as part of ultimate load.
Calibration: Traceable to NIST.
Documentation: Includes User’s Guide and signed calibration card.
Carry case/crate:
Low/Med capacity 5" dial - includes plastic carry case
Low/Med capacity 10" dial - optional steel carry case
All high capacity - includes reinforced plywood crate
Periodic proof loads: Controlled 150% proof loads permitted annually.
More product configurations and options availables upon request; please contact us for details.
| Product | Description | Pan size | Price |
|---|---|---|---|
| DIL AP1 | 500lb x 5lb | (5'') (125mm) | 1195.00 |
| DIL AP10 | 1,000lb x 5 lb | (10'') (250mm) | 1395.00 |
| DIL AP11 | 2,000lb x 10lb | (10'') (250mm) | 1395.00 |
| DIL AP12 | 5,000lb x 20lb | (10'') (250mm) | 1455.00 |
| DIL AP13 | 10,000 x 50lb | (10'') (250mm) | 1565.00 |
| DIL AP14 | 20,000 x 100lb | (10'') (250mm) | 2120.00 |
| DIL AP15 | 30,000 x 200lb | (10'') (250mm) | 5740.00 |
| DIL AP16 | 50,000 x 200lb | (10'') (250mm) | 5740.00 |
| DIL AP2 | 1,000lb x 10lb | (5'') (125mm) | 1135.00 |
| DIL AP3 | 2,000lb x 20lb | (5'') (125mm) | 1135.00 |
| DIL AP4 | 4,000lb x 25lb | (5'') (125mm) | 1225.00 |
| DIL AP5 | 5,000lb x 50lb | (5'') (125mm) | 1195.00 |
| DIL AP6 | 8,000lb x 50lb | (5'') (125mm) | 1345.00 |
| DIL AP7 | 10,00lb x 100lb | (5'') (125mm) | 1335.00 |
| DIL AP8 | 15,000 x 100lb | (5'') (125mm) | 1535.00 |
| DIL AP9 | 20,000 x 200lb | (5'') (125mm) | 1500.00 |
